Stub End buttweld fitting
ASME SA182 Duplex 2205 Stub End buttweld fitting, DIN 1.4301 Stub End buttweld fitting, Inconel 625 Stub End buttweld fitting, 2507 Super Duplex Stub End buttweld fitting.
About Stub End buttweld fitting
NISSAN STEEL Manufacturer supplier of SS, High nickel and Duplex / Super duplex Buttweld fitting, for enquiry contact on email: sales@nissansteel.com, export@nissansteel.com, nissansteels@gmail.com
UNS N08020 Stub End buttweld fitting Manufacturer, 304 Stainless Steel Stub End buttweld fitting Stockist, Duplex 31803 Stub End buttweld fitting Stockist.
Specification of Stub End buttweld fitting
| Dimensions | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43 |
| Size | EN, ISO, DIN, JIS, NPT |
| Thickness | SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75 |
| Bending Radius | R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom |
| Type | Seamless / Welded / Fabricated |
| Pressure-Temperature Class | 150LB, 300LB, 600LB, 1500LB, 2500LB. |
| Schedule | Schedule 5 TO Schedule XXS. |
| Type Of Dimension | BS1640, EN 10253 - 4, DIN 2605, JIS B2312, ANSI B16.9, MSS SP-75, ANSI B16.28, MSS-SP-43 Type A, MSS-SP-43 Type B, JIS B2313 |
Dimensions Standard Of Stub End buttweld fitting
| NPS | O.D. of barrel | Length (F) | Radius (R) | Diameter (G) | ||
| Min. | Maxi. | Long Pattern | Short Pattern | |||
| 1/2″ | 20.5 | 22.8 | 76 | 51 | 3 | 35 |
| 3/4″ | 25.9 | 28.1 | 76 | 51 | 3 | 43 |
| 1″ | 32.6 | 35.0 | 102 | 51 | 3 | 51 |
| 1 1/4″ | 41.4 | 43.6 | 102 | 51 | 5 | 64 |
| 1 1/2″ | 47.5 | 49.9 | 102 | 51 | 6 | 74 |
| 2″ | 59.5 | 62.4 | 152 | 64 | 8 | 92 |
| 2 1/2″ | 72.2 | 75.3 | 152 | 64 | 8 | 105 |
| 3″ | 88.1 | 91.3 | 152 | 64 | 10 | 127 |
| 3 1/2″ | 100.8 | 104.0 | 152 | 76 | 10 | 140 |
| 4″ | 113.5 | 116.7 | 152 | 76 | 11 | 157 |
| 5″ | 140.5 | 144.3 | 203 | 76 | 11 | 186 |
| 6″ | 167.5 | 171.3 | 203 | 89 | 13 | 216 |
| 8″ | 218.3 | 222.1 | 203 | 102 | 13 | 270 |
| 10″ | 272.3 | 277.2 | 254 | 127 | 13 | 324 |
| 12″ | 323.1 | 328.0 | 254 | 152 | 13 | 381 |
| 14″ | 354.8 | 359.9 | 305 | 152 | 13 | 413 |
| 16″ | 405.6 | 411.0 | 305 | 152 | 13 | 470 |
| 18″ | 456.0 | 462.0 | 305 | 152 | 13 | 533 |
| 20″ | 507.0 | 514.0 | 305 | 152 | 13 | 584 |
| 22″ | 558.0 | 565.0 | 305 | 152 | 13 | 641 |
| 24″ | 609.0 | 616.0 | 305 | 152 | 13 | 692 |
Size Of Stub End buttweld fitting
| NPS | Outside Daimeter | T | G | F | R Type A | R Type B |
| 1/2 | 21.3 | 2.11 | 34.9 | 50.8 | 3.05 | 0.76 |
| 3/4 | 26.7 | 2.11 | 42.9 | 50.8 | 3.05 | 0.76 |
| 1 | 33.4 | 2.77 | 50.8 | 50.8 | 3.05 | 0.76 |
| 1¼ | 42.2 | 2.77 | 63.5 | 50.8 | 4.83 | 0.76 |
| 1½ | 48.3 | 2.77 | 73 | 50.8 | 6.35 | 0.76 |
| 2 | 60.3 | 2.77 | 92.1 | 63.5 | 7.87 | 0.76 |
| 2½ | 73 | 3.05 | 104.8 | 63.5 | 7.87 | 0.76 |
| 3 | 88.9 | 3.05 | 127 | 63.5 | 9.65 | 0.76 |
| 3½ | 101.6 | 3.05 | 139.7 | 76.2 | 9.65 | 0.76 |
Weight Chart Of Stub End buttweld fitting
| Normal Pipe Sizes In inches | ASME B16.9 Stub Ends | |||
| Schedule 5S | Schedule 10S | Schedule 40S | Schedule 80S |
|
| 1/2 | 0.06 | 0.08 | 0.12 | 0.13 |
| 3/4 | 0.07 | 0.09 | 0.15 | 0.17 |
| 1 | 0.09 | 0.15 | 0.20 | 0.25 |
| 1 1/4 | 0.13 | 0.20 | 0.30 | 0.35 |
| 1 1/2 | 0.16 | 0.25 | 0.38 | 0.46 |
| 2 | 0.25 | 0.40 | 0.55 | 0.75 |
| 2 1/2 | 0.35 | 0.50 | 0.80 | 1.00 |
| 3 | 0.50 | 0.60 | 1.10 | 1.50 |
| 4 | 0.70 | 1.00 | 1.80 | 2.50 |
| 5 | 1.00 | 1.25 | 2.50 | 3.50 |
| 6 | 1.60 | 1.95 | 3.70 | 5.50 |
| 8 | 2.50 | 3.10 | 5.90 | 10.0 |
| 10 | 4.00 | 4.90 | 10.5 | 14.0 |
| 12 | 6.60 | 7.10 | 15.0 | 20.0 |
| 14 | 6.40 | 7.80 | 15.5 | 20.5 |
| 16 | 7.90 | 9.00 | 18.0 | 24.0 |
| 18 | 9.30 | 10.5 | 21.0 | 28.0 |
| 20 | 12.0 | 13.5 | 23.5 | 31.0 |
| 24 | 16.5 | 19.0 | 28.5 | 38.0 |
Pressure Rating Of Stub End buttweld fitting
| ASME B16.9 Cap Pressure ratings (psig) | |||||
| Pipes Caps Temperature Ratings | Type Of Pressure Class | ||||
| 150 LBS | 300 LBS | ||||
| 1/4 - 1 Inches | 1 1/4 - 2 Inches | 2 1/2 - 3 Inches | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | - | 935 | 750 | 560 |
| 450 | 232 | - | 725 | 600 | 475 |
| 500 | 260 | - | 510 | 450 | 385 |
| 550 | 288 | - | 300 | 300 | 300 |
Price Of Stub End buttweld fitting
| Stainless Steel Buttweld Fittings | USD $2.06 - $10.07 / Piece (FOB Price) on request |
| High Nickel Alloys Buttweld Fittings | USD $8.11 - $20.21 / Piece (FOB Price) on request |
| Duplex & Super Duplex Buttweld Fittings | USD $10.21 - $35.51 / Piece (FOB Price) on request |
| Cupro Nickel Buttweld Fittings | USD $5.20 - $10.49 / Piece (FOB Price) on request |
| Carbon Steel Buttweld Fittings | USD $3.24 - $10.84 / Piece (FOB Price) on request |
Application Of Stub End buttweld fitting
We make sure that our every product is made of high quality raw material. We thoroughly test each and every product before dispatching it to our customers.
- Petrochemical Industries
- Power Generation Industries
- Food Processing Industries
- Oil & Gas Industries
- Sugar Industries
Testing Of Stub End buttweld fitting
We known for its accurate and perfect dimensions. We thoroughly test all our products before shipping them to the customers. We carry out destructive as well as non-destructive tests on all our products.
- Eddy Current Examining
- Hydrostatic Analysis
- Pitting Protection Test
- Power Generation Industries
- Positive Material Recognition
Packing Of Stub End buttweld fitting
We uses the most safest and the most effective ways of packaging for all types of deliveries. We pack our goods in various ways such as:
- Wooden Boxes
- Wooden Pallets
- Shrink-Wrapped
- Carton Boxes
- Wooden crates
